About Pro-Flow

PRO-FLOW HEAVY DUTY LARGE DIAMETER HOSE * THIS IS KEY A lightweight, heat resistant, large diameter supply hose that delivers superior flow during fireground operations. Ozone and chemical resistant, the nitrile/PVC through-the-weave design allows the hose to expand under pressure - decreasing friction loss and increasing water flow. Key Hose, on request, will supply written warranties that Pro-Flow hose meets a minimum 10,000 cycles.

Technical details of Pro-Flow

Scope

A lightweight, heat resistant, large diameter supply hose that delivers superior flow during fireground operations.

Jacket Construction

Ozone and chemical resistant, the nitrile/PVC through-the-weave design allows the hose to expand under pressure - decreasing friction loss and increasing water flow.

Abrasion

Hose shall withstand 10,000 cycles on the Taber Abrasion Machine will supply written warranties that Pro-Flow hose meets a minimum 10,000 cycles. Other abrasion test results (UL, DIN, etc.) can be supplied on request of purchaser.

Lining

Ultimate Tensile Strength - Tensile strength of the lining and cover shall not be less than 1200 psi. Red Yellow Ultimate Elongation - 400% minimum.

Couplings

Pro-Flow shall Pro-Flow coupling options are as required by purchaser, expansion carry a 10-year written warranty against defects in materials and workmanship.

Performance and Standards

Key Hose, on request, will supply written warranties that Pro-Flow hose meets a minimum 10,000 cycles. Meets or exceeds NFPA 1961. Ozone resistance references ASTM D518 Procedure B. UL listing applies by diameter and pressure rating. Carries a 10-year written warranty against defects in materials and workmanship.

Diameter specifications of Pro-Flow

Diameter	Part No.	Service Test	Proof Test	Burst Test	Bowl Size	Weight Uncoupled	UL Listing
3"	RC30-600	300 psi	600 psi	900 psi	33/8"	0.60 lbs/ft	UL listed to 300 psi
4"	RC40-500	250 psi	500 psi	750 psi	41/4"	0.74 lbs/ft	UL listed to 200 psi
5"	RC50-450	225 psi	450 psi	675 psi	51/4"	0.93 lbs/ft	UL listed to 200 psi
6"	RC60-450	225 psi	450 psi	675 psi	61/4"	1.35 lbs/ft
