Combat Sniper is engineered for low pressure nozzle applications with targeted flow ranges of 145-175 gpm. An operational game-changing attack line with legendary, double jacketed, extruded through-the-weave nitrile/PVC tube construction and true 1.78" diameter. UL Abrasion - The hose shall pass a burst test after 500 cycles on a reciprocating abrasion tester - as specified in UL Standard 19.
Combat Sniper is engineered for low pressure nozzle applications with targeted flow ranges of 145-175 gpm.
An operational game-changing attack line with legendary, double jacketed, extruded through-the-weave nitrile/PVC tube construction and true 1.78" diameter.
HANDLING FLOW FRICTION LOSS KINK RESISTANCE DURABILITY NOZZLE PRESSURE 100 75 50 psi TARGETED FLOW WITH PRECISE HANDLING Safety Factors Abrasion Resistance - A direct relationship to the safe performance of the fire hose.
The hose shall have no apparent damage to cover reinforcement or lining when subjected to the following cold flexibility test: a 50' length of dry hose is coiled and placed in a cold box at -65 °F for a duration of 24 hours.
Connection options are available to match apparatus and deployment preferences.
Abrasion Resistance - A direct relationship to the safe performance of the fire hose. The UL abrasion test most closely resembles the fire ground use of fire hose and as such, is considered of prime importance. Meets or exceeds NFPA 1961. Ozone resistance references ASTM D518 Procedure B. UL listing applies by diameter and pressure rating. Carries a 10-year written warranty against defects in materials and workmanship.
| Diameter | Part No. | Service Test | Proof Test | Bowl Size | Weight Uncoupled |
|---|---|---|---|---|---|
| 1.78" | DP17-100S | 500 psi | 1000 psi | 2.125" | 0.40 lbs/ft |
Big-10
1" | 400 psi service
Combat-Ready
13/4" | 500 psi service
Combat-Sniper
1.78" | 500 psi service
Dura-Flow
1" | 300 psi service
Eco-10
11/2" | 400 psi service
Hy-Flow
4" | 300 psi service
Key-Lite
1" | 400 psi service
Magnum
11/2" | 400 psi service
Pro-Flow
3" | 300 psi service
Pro-Flow-HP
300 psi service
TRU-ID
1.75" | 400 psi service
