Industrial-LDH | Key Hose

Color Swatch Options

About Industrial-LDH

Industrial LDH features an oversized inner diameter that is engineered to fit most couplings. INDUSTRIAL LDH LARGE DIAMETER LAY FLAT HOSE KEY The workhorse of industrial hoses, featuring a rugged and reliable construction that has it all - heat/cold, chemical and ozone resistant. The nitrile/PVC through-the-weave design with smooth, reinforced inner liner that allows the hose to expand under pressure - increasing water flow and keeping friction loss to a minimum.

Technical details of Industrial-LDH

Scope

The workhorse of industrial hoses, featuring a rugged and reliable construction that has it all - heat/cold, chemical and ozone resistant.

Jacket Construction

INDUSTRIAL LDH LARGE DIAMETER LAY FLAT HOSE KEY The workhorse of industrial hoses, featuring a rugged and reliable construction that has it all - heat/cold, chemical and ozone resistant.

Abrasion

Hose shall withstand 10,000 cycles on the Taber Abrasion Machine will supply written warranties that Industrial LDH hose meets a mini- mum 10,000 cycles. Other abrasion test results (UL, etc.) can be supplied on request of purchaser.

Lining

Hose shall have no apparent damage to cover, reinforcement or lining when subjected to LARGE DIAMETER the following cold flexibility test: a 50' length of dry hose is to be firmly coiled and placed in a cold box at -35 °F for a duration of 24 hours.

Couplings

Connection options are available to match apparatus and deployment preferences.

Performance and Standards

The nitrile/PVC through-the-weave design with smooth, reinforced inner liner that allows the hose to expand under pressure - increasing water flow and keeping friction loss to a minimum. Ozone resistance references ASTM D518 Procedure B. UL listing applies by diameter and pressure rating.

Diameter specifications of Industrial-LDH

Diameter	Part No.	Service Test	Proof Test	Burst Test	Weight Uncoupled
4"	RC40-500	250 psi	500 psi	750 psi	0.74 lbs/ft
6"	RC60-300	150 psi	300 psi	450 psi	1.20 lbs/ft
8"	RC80-300	150 psi	300 psi	450 psi	1.95 lbs/ft
10"	RC100-300	150 psi	300 psi	450 psi	2.95 lbs/ft
