Equipment / Key Hose
Eco-5
INDUSTRIAL
About Eco-5
ECO-5 RUBBER LINED INDUSTRIAL HOSE * THIS IS KEY Lightweight, single jacket construction, combining 100% polyester ring spun staple and filament fibers over a thin wall, high tensile, EPDM rubber liner. The outer jacket is mildew resistant and available with “Key-Lok” polyurethane based polymer impregnation for unmatched abrasion and moisture resistance. Lining The rubber lining shall be a single-ply extruded tube of synthetic high tensile EPDM compounded to resist ozone.
Technical details of Eco-5
Scope
Lightweight, single jacket construction, combining 100% polyester ring spun staple and filament fibers over a thin wall, high tensile, EPDM rubber liner.
Jacket Construction
The outer jacket is mildew resistant and available with “Key-Lok” polyurethane based polymer impregnation for unmatched abrasion and moisture resistance.
Abrasion
Hose assemblies shall be available with the special “Key-Lok” poly- urethane based polymer impregnation for added abrasion resistance and ease in identification purposes. Impregnated hose shall meet the NFPA colors may be specified by the end-user.
Lining
A proprietary reverse twill weave construction reduces friction loss, while high tensile yarn combinations allow hose to be 25% lighter.
Couplings
Connection options are available to match apparatus and deployment preferences.
Performance and Standards
Scope The service test pressure of hose made to this specification shall be specifications will have a potential service life and warranty of 5 years barring shall not elongate more than 48". Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.
Diameter specifications of Eco-5
| Diameter | Part No. | Service Test | Proof Test | Bowl Size | Weight Uncoupled |
|---|---|---|---|---|---|
| 1" | SP10-600 | 300 psi | 600 psi | 13/16" | 0.10 lbs/ft |
| 11/2" | SP15-600 | 300 psi | 600 psi | 13/4" | 0.15 lbs/ft |
| 2" | SP20-600 | 300 psi | 600 psi | 21/4" | 0.17 lbs/ft |
| 21/2" | SP25-600 | 300 psi | 600 psi | 23/4" | 0.28 lbs/ft |
