Equipment / Key Hose
Flame-Out
INDUSTRIAL
About Flame-Out
FLAME OUT MSHA APPROVED MINE HOSE KEY Mine Safety and Health Administration approved, this lightweight jacketed and rubber lined fire hose features self-extinguishing properties and is guaranteed to meet the demands of underground fire. Extremely heat and cold resistant and available in single jacket or double jacket construction with high quality polyester reinforced outer jacket and durable MSHA Approved rubber liner. Curve and straight burst testing mistreatment that would render it unfit for service.
Technical details of Flame-Out
Scope
Mine Safety and Health Administration approved, this lightweight jacketed and rubber lined fire hose features self-extinguishing properties and is guaranteed to meet the demands of underground fire fighting.
Jacket Construction
Extremely heat and cold resistant and available in single jacket or double jacket construction with high quality polyester reinforced outer jacket and durable MSHA Approved rubber liner.
Abrasion
All polyester outer jackets provide superior cut, puncture and abrasion resistance while enhancing protection of a kink resistant rubber liner that guarantees reliable flow.
Lining
The filler yarns shall be constructed of high strength, low elongation, filament polyester to reduce weight and increase flexibility.
Couplings
Quality Internal expansion ring threaded couplings or as required by purchaser. The fire hose assembly supplied under this specification shall be constructed with superior quality and materials.
Performance and Standards
Curve and straight burst testing mistreatment that would render it unfit for service. Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.
Diameter specifications of Flame-Out
| Diameter | Part No. | Service Test | Proof Test | Bowl Size | Weight Uncoupled |
|---|---|---|---|---|---|
| 11/2" | SP15-MSHA | 300 psi | 600 psi | 13/4" | 0.23 lbs/ft |
| 2" | SP20-MSHA | 300 psi | 600 psi | 21/4" | 0.33 lbs/ft |
| 21/2" | SP25-MSHA | 300 psi | 600 psi | 23/4" | 0.39 lbs/ft |
| 11/2" | DP15-MSHA | 400 psi | 800 psi | 115/16" | 0.38 lbs/ft |
| 2" | DP20-MSHA | 400 psi | 800 psi | 22/5" | 0.46 lbs/ft |
| 21/2" | DP25-MSHA | 400 psi | 800 psi | 3" | 0.64 lbs/ft |
Comparison with other INDUSTRIAL hoses
Key Hose Literature
Flame-Out-IND-Spec-Sheet.pdf
