Equipment / Key Hose
Type-II
FORESTRY
About Type-II
TYPE II LIGHTWEIGHT 5100-187 FORESTRY HOSE THIS IS KEY Engineered to combat the rigors of wildland fire fighting and ideal for changing forestry terrain, providing the ultimate in heat, abrasion and puncture resistance. A heat resistant ring spun outer jacket prevents damage from sparks and radiant heat. Key Hose “smooth flow technology” delivers more water at higher pressures, all in a compact, lightweight design that goes where you need it, while easy to deploy and manage.
Technical details of Type-II
Scope
Engineered to combat the rigors of wildland fire fighting and ideal for changing forestry terrain, providing the ultimate in heat, abrasion and puncture resistance. A heat resistant ring spun outer jacket prevents damage from sparks and radiant heat.
Jacket Construction
A heat resistant ring spun outer jacket prevents damage from sparks and radiant heat.
Abrasion
Hose assemblies are available with polymer impregnation that provide additional abrasion resistance. Standard color is yellow. Color shall be pure and even in each hose. Impregnated hose shall meet the requirements of USDA 5100-187 for abrasion resistance.
Lining
TYPE II Lining The lining shall be a single-ply extruded tube of synthetic polyure- thane to resist ozone.
Couplings
Scope Expansion ring threaded or quarter-turn quick connect couplings The fire hose assembly supplied under this specification shall be constructed with available as specified by the end-user. Couplings shall meet superior quality materials.
Performance and Standards
Key Hose “smooth flow technology” delivers more water at higher pressures, all in a compact, lightweight design that goes where you need it, while easy to deploy and manage. Meets or exceeds NFPA 1961. UL listing applies by diameter and pressure rating.
Diameter specifications of Type-II
| Diameter | Part No. | Service Test | Proof Test | Burst Test | Bowl Size | Weight Uncoupled |
|---|---|---|---|---|---|---|
| 1" | FF10-600PU | 300 psi | 600 psi | 900 psi | 1 3/16" | 0.10 lbs/ft |
| 11/2" | FF15-600PU | 300 psi | 600 psi | 900 psi | 111/16" | 0.12 lbs/ft |
Comparison with other FORESTRY hoses
Key Hose Literature
Type-II-Spec-Sheet.pdf
