About Reel-Lite
REEL LITE LIGHTWEIGHT REEL FIRE HOSE THIS IS KEY The industry’s most durable and lightweight, high pressure booster hose featuring a highly abrasion and heat resistant single jacket polyester cover. This uniquely constructed • 1 year warranty against defects in material and workmanship product features an all polyester cover for heat and abrasion resistance, along with a special helical interior reinforcement to retain its rigid shape. Uniquely constructed using an interior helical reinforcement offering unmatched kink resistance that maintains hose shape and performance.
Technical details of Reel-Lite
Scope
The industry’s most durable and lightweight, high pressure booster hose featuring a highly abrasion and heat resistant single jacket polyester cover.
Jacket Construction
Circular woven, single jacket, combined with a helical interior reinforcement, and
Abrasion
Hose assemblies come standard with polymer impregnation that provides additional abrasion resistance. Standard colors are red and yellow. Color shall be pure and even in each hose.
Lining
Lining and reinforcement characteristics are specified for long service life and pressure stability.
Couplings
urethane lined hose is the most durable lightweight booster hose on the market. Field replaceable coupling with a one inch NH thread standard. Aluminum internal expansion ring coupling available upon request.
Performance and Standards
Uniquely constructed using an interior helical reinforcement offering unmatched kink resistance that maintains hose shape and performance. UL listing applies by diameter and pressure rating. Carries a 1-year warranty against defects in materials and workmanship.
Diameter specifications of Reel-Lite
| Diameter | Part No. | Service Test | Proof Test | Bowl Size | Weight Uncoupled |
|---|---|---|---|---|---|
| 1" | RB10-800 | 400 psi | 800 psi | 1 5/16" | 10 lbs |
Comparison with other FORESTRY hoses
Key Hose Literature
Reel-Lite-Spec-Sheet.pdf
