Equipment / Ramfan

VX700

Large Structure Ventilators

VX700 image

Ramfan Product Family

The VX700 is part of Ramfan's large structure ventilators lineup for fire rescue ventilation operations and incident response support.

Quantitative details of VX700

MetricValue
AirflowDouble Door 46,700 cfm
AirflowWarehouse 60,200 cfm
Weight220 lbs / 100 kg
Voltage12V
RuntimeRuntime 2 hrs
Motor/PowerEngine Honda GX630 23 Hp / 17 kW
Blade/ImpellerImpeller 7-Blade
Dimensions49 x 33.3 x 47.3 in
NoiseNoise 105 dB @ 3' (1 m) / 103 dB @ 10' (3 m)

Comparison with other Large Structure Ventilators

ProductAirflowPowerWeightRuntime
VX700 thumbnail VX700 Double Door 46,700 cfm12V220 lbs / 100 kgRuntime 2 hrs
GX500 thumbnail GX500 Double Door 27,800 cfm (47,260 m3/hr)8.5 Hp137 lbs / 62 kgRuntime 2 hrs
GX600 thumbnail GX600 Double Door 32,500 cfm (55, 250m3/hr)Engine Vanguard 18 Hp / 13175 lbs / 80 kgRuntime 2 hrs
